| Part No. | Description | Group | Ref# | 6V | 8V | 12V | 16V | Price | QOH | |
|---|---|---|---|---|---|---|---|---|---|---|
| Note: Quantities For Oil Coolers And Associated Parts On This Page Are Per Oil Cooler, Not By Engine Size. | ||||||||||
| Details | 8547547 | Core Assy., Oil Cooler - Engine (16 Plate) | 4.4001 | 01 | 1 | $874.11 | 16 | |||
| Details | 8547195 | Core Assy., Oil Cooler - Engine (18 Plate) | 4.4001 | 01 | 1 | $1,029.10 | 21 | |||
Details
|
8547551 | Core Assy., Oil Cooler - Marine Gear (8 Plate In H.E. Tank) | 4.4002 | 00 | 1 | $607.89 | 24 | |||
|
Details
|
8547556 | Core Assy., Oil Cooler - Marine Gear (16 Plate) | 4.4002 | 00 | 1 | $890.48 | 2 | |||
| Details | 5150155 | Gasket, Oil Cooler Core Inner Superceded... Click 'Details' for replacement. | 4.4030 | 02 | 1 | 1 | 0 | |||
|
Details
|
5144703 | Gasket, Oil Cooler Core Inner (Core To H.E. Tank) (5.5050) | 4.4030 | 02 | 1 | 1 | $18.03 | 1 | ||
|
Details
|
5102506 | Gasket, Oil Cooler Core Outer | 4.4040 | 03 | 1 | 1 | $6.94 | 0 | ||
|
Details
|
8923223 | Gasket, Oil Cooler Core Outer | 4.4040 | 03 | 1 | 1 | $7.01 | 16 | ||
| Details | 5129421 | Housing, Oil Cooler - Engine | 4.4050 | 04 | 1 | 1 | $1,496.83 | 34 | ||
|
Details
|
5133402 | Housing, Oil Cooler - Engine | 4.4050 | 04 | A/R | A/R | A/R | A/R | $438.01 | 20 |
| Details | 5107430 | Housing, Oil Cooler - Engine Superceded... Click 'Details' for replacement. | 4.4050 | 04 | A/R | A/R | A/R | A/R | 0 | |
|
Details
|
5129741 | Housing, Oil Cooler - Marine Gear (OBSOLETE) | 4.4050 | 04 | A/R | A/R | A/R | A/R | OBSOLETE | 2 |
|
Details
|
5104011 | Housing, Oil Cooler - Engine | 4.4050 | 04 | A/R | A/R | A/R | A/R | $758.18 | 32 |
|
Details
|
5142549 | Plug, 3/4" Pipe (12.9550) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $2.19 | 100+ |
|
Details
|
8923847 | Plug, 1/4" Pipe (4.7001) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $0.94 | 100+ |
|
Details
|
8923313 | Plug, 3/4" Pipe (W/Seal) (12.9550) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $2.69 | 100+ |
| Details | 187953 | Bolt, 5/16"-18 X 4 1/2" (12.9001) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $27.51 | 0 |
|
Details
|
186274 | Bolt, 5/16"-18 X 5" (12.9001) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $2.47 | 89 |
|
Details
|
455971 | Bolt, 5/16"-18 X 5 1/2" (12.9001) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $2.57 | 30 |
|
Details
|
215386 | Bolt, 5/16"-18 X 6" (12.9001) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $4.25 | 40 |
|
Details
|
5155596 | Washer, 5/16" Copper (12.9190) | 4.4050 | 00 | A/R | A/R | A/R | A/R | $1.93 | 100+ |
|
Details
|
103320 | Lockwasher, 5/16" (12.9200) | 4.4050 | 06 | A/R | A/R | A/R | A/R | $0.07 | 100+ |
|
Details
|
8921688 | Cover, Oil Cooler Housing (4.2240) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $1,127.25 | 7 |
| 23505252 | Cover, Oil Cooler Housing (OBSOLETE) | 4.4060 | 00 | A/R | A/R | A/R | A/R | OBSOLETE | 0 | |
| Details | 5167775 | Cover, Oil Cooler Housing (H.E. Tank/Marine Gear) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $476.84 | 14 |
|
Details
|
5117733 | Cover, Oil Cooler Housing (Bottom) (1.1060) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $28.20 | 15 |
| 8927273 | Cover & Valve Assy., Oil Cooler Housing (For Single Oil Cooler) (OBSOLETE) | 4.4060 | 00 | A/R | A/R | A/R | A/R | OBSOLETE | 0 | |
| 8927272 | Cover & Valve Assy., Oil Cooler Housing (For Double Oil Cooler) (OBSOLETE) | 4.4060 | 00 | A/R | A/R | A/R | A/R | OBSOLETE | 0 | |
| 8927271 | Cover & Valve Assy., Oil Cooler Housing (For Remote Mtd. Filter) (OBSOLETE) | 4.4060 | 00 | A/R | A/R | A/R | A/R | OBSOLETE | 0 | |
|
Details
|
23503626 | Valve, Oil Cooler Housing (4.2245) Superceded... Click 'Details' for replacement. Replaced by 4 items. | 4.4060 | 00 | A/R | A/R | A/R | A/R | 1 | |
|
Details
|
5575086 | Gasket, Oil Cooler Housing (4.2489) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $10.02 | 27 |
|
Details
|
5103892 | Insert, Oil Cooler Housing (4.2240) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $20.80 | 7 |
|
Details
|
5133431 | Valve, Oil Cooler Housing (4.2485) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $5.44 | 93 |
|
Details
|
5133594 | Spring, Oil Cooler Housing (4.2486) | 4.4060 | 00 | A/R | A/R | A/R | A/R | $17.58 | 9 |
| GROUP 4.4060 CONTINUED ON NEXT PAGE | ||||||||||
